床身上大工件直徑Max. Swing over bed

400mm

400mm

500mm

500mm

610mm

610mm

刀架上大工件直徑Max. Swing over carriage

210mm

210mm

300mm

300mm

370mm

370mm

馬鞍槽大工件直徑Max. Swing in gap

630mm

720mm

830mm

馬鞍槽有效長度Effective gap length

210mm

210mm

210mm

大工件長度Max. Length of work piece

750mm or 1000mm or 1500mm or 2000mm

床身寬度Width of bed

400mm

刀桿截面Section of turning tool

25X25mm

主軸Spindle

主軸轉速范圍Spindle speeds

11—1600 r/min (24 steps)

主軸內孔Hole though spindle

52mm(80mm)

主軸孔錐度Spindle taper

Morse No.6 (莫氏6號)

進給Feed

進給數量No. of feeds

64種(kinds)(for each)

公制螺紋Range of metric threads (kinds)

(1-192mm)44種(44kinds)

英制螺紋Range of inch threads(kinds)

(1-24tpi)21種(21kinds)

模數螺紋Rage of module threads(kinds)

0.25-48(模數39種)(Module 39 kinds)

徑節螺紋Rage of Diametral pitc threads (kinds)

1-96DP(37種)(37 kinds)

床尾 ：Tailstock

床尾主軸大行程Max tailstock spindle travel

150mm

床尾主軸直徑Tailstock spindle diameter

75mm

床尾主軸孔錐度

Morse No.5 (莫氏5號)

主電機Main motor

7.5KW(10HP)
